Description
Signage Totem advertising
This screen provides a dynamic display of interactive 10 points, and is the solution of the diffusion of electronic catalog perfect for use as a kioske of sale or the information and guidance in the high-traffic areas.
Multimedia player all-in-one
A powerful multimedia player quad-core allows you to play photos and videos, while the onboard memory of 16 Gb offers plenty of storage space for files and multimedia content.
Media player USB
Photos, music and videos to 4K can be quickly displayed on-screen directly from a USB key.
Access to web content
Thanks to the connectivity RJ45 built-in, the screen offers easy navigation on the web. Users can perform searches online and watch videos directly on the screen without having to connect to other devices.
Integrated programming
A programming interface that is effective and user-friendly interface is available via the on-screen display (OSD). The configuration features include programming of the time and the date, which helps to ensure that messages, pictures or videos are broadcast without a problem and on time.
Management of the remote display
Compatible with the control systems professional, such as Crestron, AMX, Extron, Control4, SureMDM and Revel Digital, this ePoster allows the it department to manage and configure the settings remotely via a local area network.
Location built-in media player with security gate
A location to media player a practical and can accommodate a PC or a drive additional third-party, while a lockable door allows you to secure the whole. The support ePoster also features a built-in power supply, which eliminates the need to find other outlets for additional devices.
Dual speakers 10W
Designed with two integrated speakers, this display combines a display amazing with stereo sound for an immersive multimedia immersive.
Design premium
This kiosk digital all-in-one characterized by a stylish design and end-of-high-quality using a tempered glass front 7AM which provides protection anti-scratch for your ePoster remains like new year after year.
4K resolution
With a resolution four times higher than Full HD, this screen Ultra HD 3840×2160 offers a breathtaking experience with immersive images that are vibrant, clear and also larger than in reality.
Input/output Ports
- LAN
- RS-232C
- Audio In
- S/PDIF
- PC In
- Touch Out
- USB 2.0
- HDMI
- DP In
- AC In
- Power Swithch
- AC Out
- RJ45
- USB x2
SPECIFICATIONS
- Display
Screen size: 55 inch
Type/Technology: TFT LCD (Plate GOES, backlight DLED)
Display size (mm): 1209.6 (H) * 680.4 (V)
Display Ratio: 9:16
native resolution: 2160 x 3840
Color: 1.07 billion
Brightness: 450 nits (typ.)
Ration of contrast: 1300:1 (typ.)
Response time: 9 ms (typ. G to G)
Angles of vision: H = 178, V = 178 typ.
Backlight life: 30 000 hours Typ.
Surface treatment: Tempered glass 7H
Orientation: Portrait - Touch
Type/Technology: Infrared
Resolution:touch 32768 x 32768
Points of contact: 10 Points - Inputs
HDMI: (2.0) x 3
RGB / VGA: x1
DisplayPort: (1.2) x 1
Audio: x1 PC audio(3.5 mm)
RS232: x1
- Outputs
Audio: x1 (headphone Output)
SPDIF: x1 - LAN
RJ45: x1
- USB
Type: x3 (2.0)
Type B: x2 (to the touch) - Speakers
10W x 2
- Compatibility
RGB PC/HDMI PC: 1920×1080 @60Hz
HDMI: 2160 x 3840 @60Hz
DisplayPort: 2160 x 3840 @60Hz - Android Version
8
- Multimedia
"Image: JPG, BMP, PNG
Video: MP4, MOV, MKV, DAT, MPG, MPEG, AVI, TS, WMV,RM,RMVB
Audio: MP3,WAV,AAC - Embedded software
Revel Digital, SureMDM
- Power supply
Voltage: 100-240VAC +/- 10%
Consumption: "Normal 126 W, Max 149 W (max.)
< 0.5W (Off) » - Operating Conditions
Temperature (º C): 0°C to 40°C
Humidity: 20% ~ 80%, non-condensing - Dimensions (L x H x P)
Physical (inch / mm): 30.26 x 73.62 x 17.72 in/768.5 x 1870 x 450 mm
Packaging (inch / mm): 38.19 x 80.08 x 23.98 in/970 x 2034 x 609 mm - Weight
Net (lb / kg): 138.23 lbs/62.7 kg
Gross (lb / kg): 164.69 lbs/74.7 kg - Regulations
cTUVus, FCC, Energy Star, CE, CB, RoHS, ErP, EEI, WEEE, BSMI
- Package contents
"1. Power cord
2. Remote control with batteries
3. Quick start Guide
4. Key*The current content can be different from one market to the other," - UPC Code
76690700690 2
