Description
Features VM46R-U
Content Options flexible and dynamic with powerful video wall integrated SoC
The VMR-U Samsung is a video wall built-in SoC powerful and effective that it can easily transform the screen of the display autonomous content as a cohesive unit without the need of additional hardware. The VMR-U is the best solution to capture and retain the attention of your customer.
VM46R-U System-on-chip (SoC)
The VMR-U is equipped with the technology of system-on-chip (SoC) integrated, allowing the screens to switch easily between viewing the contents of the individual and work together to display a coherent image. This can be done with a simple loop HDMI or a LAN connection, eliminating the need for an external media player.
Platform smart-signaling-Samsung (SSSP)
The platform SMART Signage Platform (SSSP) for Samsung, powered by Tizen 4.0, supports a user-friendly Web environment for development through enhanced compatibility with formats and Web standards.
It allows updates to content in real-time and without effort, which are needed in this rapidly changing industry.
Transparent content
* The example of the conventional display represents the operation without Tizen OS.
* A black screen may appear briefly between frames, if the content is encoded at a frame rate different.
The VMR-U offers a transparent content with the low-end, while the powerful performance of MagicINFO S Player create smooth transitions between the content without lag, black screens or gaps during playback.
Operation 24h/24 and 7d/7
Designed to maintain performance in various indoor environmental conditions, the VMR-U enables the dissemination of content lively and reliable for all the needs of the business with a continuous operation 24h/24 and 7d/7.
Panel anti-glare
The VMR-U is equipped with a panel anti-reflective coating that distributes light evenly on the screen for maintaining the brilliance and accuracy of the content, with a high contrast ratio to display content that is vivid and memorable.
Durable and reliable
Each screen VMR-U is equipped with a panel reinforced for long term performance. The top panel prevents the darkening of the screen, light leaks, and deterioration of the image.
Color Expert Pro Mobile
The solution Color Expert Pro Mobile Samsung makes calibration quick and easy video wall via a mobile camera.
Thanks to the intuitive user interface of the solution, even non-experts can simultaneously adjust the white balance up to 5×5 video wall without the need for additional equipment.
Panel
- Diagonal size46" VM46R-U
- TypeD-LED DID
- Resolution1920*1080 (Full HD)
- Pixel pitch(mm)0.53025 mm(H)*0.53025 mm(V)
- Active display area(mm)1018.08 mm*572.67 mm
- Brightness (Typ.)500 nits
- Contrast ratio3500:1
- Angle of view (H/V)178/178
- Response time (G to G)8ms
- Display colors8 bit – 16.7 M
- Range of colours72%
- Opening hours24/7
- Mist25 % (haze outdoor 23 %)
Display
- C/R dynamicMEGA DCR
- Scanning frequency H30kHz ~ 81kHz
- Scanning frequency V48Hz ~ 75Hz
- Frequency of pixels maximum148,5 MHz
Connectivity VM46R-U
Enter
- RGBDisplay Port 1.2
- VideoHDMI 2.0 (2)
- HDCPHDCP 2.2
- USBUSB 2.0 x 1
Production VM46R-U
- RGBHDMI (loop-through output)
- audioMini-jack stereo
- External controlRS232C (in/out), RJ45
- External sensorType detachable (IR, ambient)
Power VM46R-U
- TypeInternal
- Current SourceAC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Power consumption
- Max[W/h]143
- Typical[W/h]96
- BTU (maximum)488
- Standby Modeless than 0.5 W
- Stopless than 0.5 W
Specification mechanical VM46R-U
Dimensions (mm)
- Set1022.1 X 576.6 X 97.4
- Package1153 X 724 X 295
weight (kg)
- Set15,9 kg
- Package21.7 kg
- VESA mount (mm)600 * 400 (mm)
- Width bezel (mm)2.3 mm (U/L), 1.2 mm (R/B)
Operation
- Operating temperature0 ℃ ~ 40 ℃
- Humidity10 % ~ 80 %
