Description
Features SH37F
Maximize the space and optimize the content with Samsung SMART Signage
Digital signage today must be versatile and cost-effective by putting the emphasis on maximizing space efficiency. There has been a growing need to use spaces niche with solutions for efficient signaling. The screens of the series SHF Samsung, with wide screen stretched 16:4,5, offer the ability to effectively communicate information in small areas and narrow, such as store shelves, ceilings, and corridors.
When they are used in a transportation environment 24 hours on 24, 7 days on 7, the screens of the Samsung series SMART Signage SHF are an invaluable asset to keep travelers informed of the schedule changes by providing information in a clear, easy to read, and dynamics that can be consumed at a glance.
In retail environments, the screens of the series SHF offer unique opportunities to promote products or entice customers with product information using minimal space. With the ability of continuous operation 24 hours on 24, 7 days on 7, you can be assured that the attention of the customers will be at its highest level.
Deliver sharp images in various lighting conditions
The screens of the Samsung series SMART Signage SHF deliver images that are vibrant and realistic, providing an unmatched visual experience. With brightness levels of up to 700 nit, these displays offer the sharpest images and most rich, regardless of the lighting conditions. The screens of the series SHF excellent in situations with strong light where glare may present an issue. With a panel anti-glare (44 % haze), you can be assured that your content will not be obstructed by lighting conditions outside of your control, and you can be sure that your content will look great anywhere.
Customize the content of the portrait to landscape and display with simplicity
The screens of the series SHF Samsung offering the ability to pivot as well as a software of image rotation can change the orientation of the image from portrait to landscape for greater flexibility in display. The images do not require rotation in image-editing software to make them appear correctly in a different orientation as this capability is handled automatically within the display. The wide-screen format 16:4.5 allows you to create an interactive experience a rich variety of ways in a variety of spaces. The content is fully optimized and the display allows for greater flexibility since it can adapt to the content in any orientation. Easily distribute images are vibrant and realistic with ease and simplicity. During the reading of the contents of size 540×1920, the mode pivot makes it optimal.
Maximize the engagement of spectators in a minimum of space
The screens of the series SHF Samsung exhibit a slim profile with a depth of only 39,9 mm, which allows you to maximize the space available. This allows the screen to be installed in areas where space is limited and allows content to blend seamlessly into the environment in a slim and lightweight design, with a reduced energy consumption for lower operating costs. A design of bezel thin only a 13.9 mm (T/B) and 7.5 mm (L/R) allows for fewer distractions in the content and allows your message to shine in a clear and uninterrupted.
Daisy-chain connection with multiple monitors without any additional equipment
Because of the relative novelty of UHD in the display settings shopping, few media players currently offer support for streaming UHD. To meet this demand, Samsung launched an SBB compatible UHD option, which can be attached to the back of the series SHF. The simple installation of this SBB eliminates the clutter of unnecessary cables and also removes the need to create separate housing for the media player.
Specifications SH37F
Panel SH37F
- Diagonal size37"
- Type60 Hz E-LED BLUE
- Resolution1920*540
- Pixel pitch(mm)0,4686(H) x 0,4686(V)
- Active display area(mm)899.712(H) x 253.044(V)
- Brightness (Typ.)700 nits
- Contrast ratio4000:1
- Angle of view (H/V)178:178
- Response time (G to G)16ms
- Display colors8bit – 16.7 M
- Range of colours72%
- Opening hours24/7
- Mist44%
Display SH37F
- C/R dynamic10 000:1
- Scanning frequency H54 ~ 69,75 kHz
- Scanning frequency V48 ~ 62HZ
- Frequency of pixels maximum148,5 MHz
Connectivity SH37F
Enter
- RGBDVI-I, Display Port 1.2
- VideoHDMI
- HDCPHDCP 2.2
- audioMini-jack stereo
- USBUSB 2.0 x 1
Production
- RGBDP1.2 (loop-out)
- audioMini-jack stereo
- External controlRS232C (in/out) via mini-stereo jack, RJ45
- External sensorIR
- TunerNo
POWER SH37F
- TypeInternal
- Current SourceAC 100 – 240 V~ (+/- 10 %), 50/60 Hz
Power consumption
- Max[W/h]77
- Typical[W/h]56
- BTU (maximum)263
- Standby Modeless than 0.5 W
- Stopless than 0.5 W
Specification mechanical SH37F
Dimensions (mm)
- Set914,9 × 280,8 × 39,9
- Package1102 X 122 X 369
weight (kg)
- Set6.6
- Package8.5 kg
- VESA mount (mm)400 X 200
- Media TypeFoot Support (optional)
- Width bezel (mm)5,7 (side), 12 (top/bottom)
Operation
- Operating temperature101 ℃ ~ 40,0 ℃
- Humidity10,0 % ~ 80,0 %
