Description
QB98R
Give a new dimension to your display
The new screens of the series QBR Samsung stand out by offering the best resolution UHD-in-class technology intelligent upscaling UHD, as well as rich colors and realistic with Dynamic Crystal Color all in a frame design, ultra-thin.
An amazing image quality, 4K
The new series QBR Samsung offers a 4K resolution ultra-high resolution, creating lifelike images with an image quality that is sharper than ever.
Smart technology upscaling UHD
The smart technology upscaling UHD Samsung provides a restoration of the edges and a noise reduction to provide an image quality UHD perfect, even with a content of lower resolution. This solution fit for the future " provides unsurpassed image quality, regardless of the resolution of the original content.
Perfect visibility thanks to the reflective display
The screens of the series QBR are equipped with plates, anti-reflective reliable and offer excellent visibility at all angles, at any time of the day. Thus, the companies can provide accurate and clear information 24h/24 and 7d/7 in places where these information are essential, such as airports and train stations in the suburbs.
A powerful solution all-in-one
The platform SSSP (Samsung Smart Signage Platform) is a solution all-in-one, which simplifies installation and maintenance. Based on Tizen os 4.0, it allows enterprises to take advantage of a simple development, with enhanced compatibility with many formats and Web standards, and a secure protection.
Wi-Fi and Bluetooth built-in
Technologies Wi-Fi and Bluetooth built-in allow us to provide more personalized services and interactive, while simplifying the presentation of content for businesses. Whether it's to simplify the operation of the network or deploying the technology of beacons interactive in-store, the screens of the series QBR help the traders to look into the future of retail.
The image is provided for illustration purposes only. The usage scenario described may require the development of an application or a specific program.
Specifications QB98R
Screen
- Diagonal98"
- Type of slabDirect LED
- Resolution3.840 x 2.160
- Pixel Pitch (HxV)187,4 x 562,2 (um)
- Brightness350
- Contrast4.000:1
- Angle of view (H/V)178/178
- Response time6ms
- Gamut72%
- Anti-reflective glass25%
- Horizontal scanning frequency60Hz
- Maximum scan rate594MHz
- Vertical scanning frequency135kHz
- Dynamic contrast ratioMega Contrast
Connectivity
- HDMI In2
- DP entryYes
- DVI input1
- USB2
- IR inputYes
- Input HDBaseTNo
- Audio InputYes
- Audio OutputStereo Mini Jack
- Video OutputHDMI
- Input RS232Yes
- RS232 outputYes
- RJ45 inputYes
- Output RJ45No
- Wi-fiYes
- BluetoothYes
Energy Consumption
- Power supplyAC100-240V 50/60Hz
- Power consumption (OFF Mode)0,00 W
- Consumption under tension (W/h)528
- Standby power consumption0.5 W
Dimensions
- Product Dimensions net (w x h x d)2194,2 x 1249,8 x 75.3 mm
- Dimensions of the product in its original packaging (w x h x d)2500 x 1618 x 815 mm
Weight
- Product weight77,1 kg
- Weight of the product in its packaging144 kg
Terms of use
- Temperature0℃~ 40℃
- Humidity10 ~ 80%, non-condensing
VESA specifications
- Dimensions of the VESA mount900 x 600 mm
- Size of the borders15,2
- Material of the FrameNon-shiny
Optional features
- Wall mountWMN9500SD
Internal player (MagicInfo)
- Support MagicInfo Daisychain VideowallYes
Eco
- Energy efficiency classB
