Description
LED technology Full HD / Philips BDL5588XH/02
The white LEDS are semiconductors that allow you to quickly get a bright and homogeneous, and thus save the development time. LEDS do not contain mercury, and are compliant with the recycling process and disposal that is respectful of the environment. LEDS allow for better dimming control of LCD backlight,resulting in super high contrast ratio. The color reproduction is optimal thanks to consistent brightness across the screen.
Display technology IPS
Screens Philips IPS use advanced technology, which widens the viewing angle 178/178 degrees,which allows you to view the screen from virtually any angle-even in Portrait mode! The IPS screens produce images incredibly sharp with vibrant colors,ideal for video walls and professional applications bulletin boards that require accurate color and a constant brightness continuously.
High brightness
Enjoy clearer images,even in bright lighting conditions,thanks to this slab 700 nits. Your target has higher image quality in places very bright without being directly sunny,for an optimized experience.
SmartControl
Connect and control your video wall from a computer-from the central administration. SmartControl is a software built into the screen,which allows you to manage your own wall of monitors from a single location via RJ45 connections and RS232. You can easily identify the different screens and optimize the parameters:resolution,brightness,contrast, and SmartPower.
FailOver
The preservation of the content is critical for demanding commercial applications. Although a disaster is unlikely,FailOver provides protection 24 hours on 24 and 7 days on 7, thanks to a revolutionary technology that displays your content backed up on the screen in case of failure your media player. FailOver is automatically result in the event of failure of the main source. Simply select the connection from the primary source, and the connection FailOver for immediate protection.
SmartPower
It is possible to pre-define and control the intensity of the backlight in order to save up to 50% energy,which is a substantial savings.
Characteristics Philips BDL5588XH/02
| TECHNICAL DETAILS Philips BDL5588XH/02 | |
| Color | Black |
| TECHNICAL DETAILS | |
| RS-232C | Yes |
| SCREEN | |
| Number of colors | 1,073 billion colors |
| Ratio of image format | 16:9 |
| SCREEN | |
| Response time | 12 ms |
| Brightness | 700 cd/m2 |
| Diagonal glassware (cm) | 138,7 cm |
| Contrast ratio | 1700:1 |
| Contrast ratio (dynamic) | 500000:1 |
| Horizontal viewing Angle | 178° |
| Vertical viewing Angle | 178° |
| Pixel pitch | 0,63 x 0,63 mm |
| Graphics resolutions supported | 640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 768 (WXGA), 1280 x 800 (WXGA), 1360 x 768 (WXGA), 1366 ? 768, 1440 x 900 (WXGA+), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA) |
| Type HD | Full HD |
| SCREEN | |
| Screen Type | LED |
| SCREEN | |
| projector-type background LED | Direct-LED |
| WEIGHT AND DIMENSIONS | |
| Width | 1213,4 mm |
| Depth | 103,3 mm |
| Height | 686,9 mm |
| Weight | 29,2 kg |
| ENVIRONMENTAL CONDITIONS | |
| Relative humidity (storage) | 20 – 80% |
| CONNECTIVITY | |
| Quantity of ports DVI-D | 1 |
| CONNECTIVITY | |
| DVI Port | Yes |
| Composite video input | 1 |
| Amount of HDMI ports | 2 |
| Amount of Displayport interface | 2 |
| CONNECTIVITY | |
| Component input of the audio visual (YPbPr/YCbCr) | 1 |
| CONNECTIVITY | |
| input ports VGA (D-Sub) | 1 |
| CONNECTIVITY | |
| Audio connector (L,R) integrated | 1 |
| SCREEN BDL5588XH/02 | |
| Screen size | 138,7 cm (54.6") |
| Screen resolution | 1920 x 1080 pixels |
| AUDIO | |
| Built-in speakers | Yes |
| ENVIRONMENTAL CONDITIONS | |
| Operating temperature | 0 – 40 °C |
| Non-operating temperature | -20 – 60 °C |
| CONNECTIVITY | |
| Audio Output (Left, Right) | 1 |
| CONNECTIVITY | |
| USB Port | No |
| CONNECTIVITY | |
| Number of ports DVI-D/DVI-I | 1 |
| PACKAGING | |
| User manual | Yes |
| POWER MANAGEMENT | |
| Power consumption (standby mode) | 0.5 W |
| Power consumption | 175 W |
| OTHER FEATURES | |
| Product name | BDL5588XH |
| ENVIRONMENTAL CONDITIONS | |
| Operating Altitude | 0 – 300 m |
| PACKAGING | |
| Càbles included | Sector, RS-232, VGA |
| PACKAGING | |
| Control â distance from the portable | Yes |
| SPEAKERS | |
| Number of speakers | 2 |
| PERFORMANCE BDL5588XH/02 | |
| Supported video Modes | 480i,480p,576i,576p,720p,1080i,1080p |
| NETWORK | |
| Number of ethernet LAN port (RJ-45) | 1 |
| OTHER FEATURES | |
| Ethernet/LAN | Yes |
| Quick start Guide | Yes |
| CERTIFICATE | |
| Energy Star Certified | Yes |
| Certification | CE, UL/cUL, CB, GOST, EPEAT, FCC, Class B |
| DESIGN | |
| Design | Digital signage flat panel |
| ERGONOMICS | |
| Compatible with VESA-standard | 400 x 400 mm |
| VESA mounting | Yes |
| Display â-screen display (OSD) | Yes |
| Multilingual display â the screen | ARA, CHI (SIMPL), CHI (TR), German, English, Spanish, French, Italian, JPN, POL, RUS, TUR |
| Number of OSD languages | 12 |
| PERFORMANCE | |
| Plug and Play | Yes |
| COMPUTER SYSTEM | |
| Computer system | No |
| MULTIMEDIA | |
| RMS rated power | 20 W |
| PACKAGE CONTENTS | |
| Batteries included | Yes |
| Warranty card | Yes |
| OTHER FEATURES | |
| Infrared Port | Yes |
| REPRESENTATION / IMPLEMENTATION | |
| Ambient light sensor | Yes |
