OVERVIEW CDE9800
The ViewSonic® CDE9800 is a presentation screen 98 " 4K Ultra HD for the meeting rooms. This screen provides a presentation that is immersive and high-impact with a resolution of stunning 3840 x 2160a high brightness-typical 500 nits, viewing angles are wide, two-speaker 16 W software and content sharing. The software ViewBoard® Cast built-in allows wireless streaming of content from mobile devices on the screen. In addition to the HDMI and VGA inputs to connect to a variety of devices high definition, this screen uses a multi-core processor built-inallowing customers to play multimedia content via USB without the need of a PC. To make your life easier, the software vController™ offers easy maintenance and intuitive interfaces for remote management via a PC server or laptop.
4K resolution Ultra HD
With a resolution four times greater than Full HDthis screen Ultra HD 3840×2160 offers a viewing experience that is breathtaking with images, immersive, vibrant, clear, and as large as nature.
4K resolution
CDE9800 Display wireless presentation on all devices
With the support of Windows, Mac, Chrome, Android and iOS, ViewBoard® Cast allows you to present wirelessly from mobile devices on the screen. Multiple users can annotate at the same time to content on their devices in real time through the display in a 4 screen split.
Software content shared on site, ViewBoard® Cast
Plug-and-Play USB
A powerful media player multi-core allows playback of photos, music and videos in just a few seconds using a simple USB connection.
USB playback Photos, music and video
Remote management
The software vController™ provides a simple and intuitive interface for remote management, the parameters related to the OSD and planning on the screens deployed via RS232 or LAN.
Software configuration display vController™
HDMI pass-through CEC
Thanks to the functionality HDMI CEC, the remote control signals may be transmitted via a HDMI cable to HDMI devices that are connected. This allows you to directly control DVD drives, audio systems and other devices out of sight with the remote control of the screen for a wider range of visualization possibilities.
Local control HDMI CEC
CDE9800 | integrated LAN, Wi-Fi optional, Internet browser
Free RJ45 integrated, as well as capabilities Wi-Fi optionaloffer network connection options for easy dissemination of content. A built-in Web browser allows a simple broadcast content via a connection to the Web.
- Internal speakers
- Support mural compatible VESA® 800 x 600 mm
- Menu commands
- Switch
- AC input
- HDMI output
- SPDIF
- USB Type A x2
- DisplayPort
- HDMI x2
- VGA
- Audio input
- Input RS232
- lan x2
- DisplayPanel size : 98"
Type/ Tech : LCD Module TFT with LED backlight
Display area (mm) : 2158,848 mm*1214,352 mm
Native resolution : 3840 x 2160
Image Format : 16:9
Color : At 1.07 B (10bit)
Brightness : 500 nits( typ.)
Contrast ratio : 1300:1
Response time : 5 ms (typ.)
Angles of vision : H = 178, V = 178 (typ.)
Backlight life : 30 000 h (min.)
Surface treatment : 3H, Haze 1 % ( typ)
Bezel : 20,3 mm
Orientation : landscape - ENTERHDMI : x2
1 port to support CEC
RGB / VGA : 1
DisplayPort : DP1.2 x1
Audio : PC audio input (3.5 mm) x1
RS-232 : x1
OPS : OPS x1
MDS-L x1 - PRODUCTIONHDMI : HDMI2.0 x1
Audio : Headphone output 3.5 mm x1
SPDIF : x1
- local area networkRJ45 : X2
10M/100 - USBType : USB2.0 x2
- SPEAKERSSPEAKERS : 16 W x2
- COMPATIBILITYHDMI : HDMI input : 4k@60Hz
HDMI output : 1080/4k @60Hz
DisplayPort : 3840×2160@60Hz
Android Version : Resolution : 1080p - POWERVoltage : 100-240 VAC +/- 10 %
Consumption wide range : Power : 385 W (Typ.)
Arrêt : <0,5 W - ERGONOMICSWall mount (VESA®) : 800 x 600 mm
- OPERATING CONDITIONSTemperature (º C) : 0°C to 40°C
Humidity : 20% ~ 80% RH non-condensing - DIMENSIONS (L x H x P)Physical (mm) : 2198.8*109.5*1253.8 mm
Packaging (mm) : 2525*435*1750mm - LESTERNet (kg) : 98,15 kg
Gross (kg) : 153,65 kg - REGULATIONSREGULATIONS : cTUVus-
FCC/ICES-003 Class B-
EPEAT
ES8
Mexico CoC
Mexico Energy
EMC/CE-EU
CB-EU
RoHS Green BOM & RoSH DoC
REACH
WEEE (Doc & Disassebly report)
ErP
EAC (local application)
UKrSEPRO (local application) - PACKAGE CONTENTSPACKAGE CONTENTS : 1. Power cord US/EU/UK/AU 3M
2. Qsg system
3. Declaration of conformity
4. HDMI cable 3M*1
5. Remote control with AAA batteries
6. Plate webcam
7. Wall-mount screw
