Description
INTRODUCTION CDE7520W
The ViewSonic® CDE7520 is a presentation screen wireless 4K 75 “. The software screen sharing built-in *, ViewBoard® Cast and Display, as well as dongles ViewBoard® Cast USB-C / HDMI allow multiple users, on-site or online, to participate in conferences and to share content between them simultaneously, transforming the CDE7520 a hub of dynamic content. This presentation screen reliable is equipped with a quad-core processor and an internal memory, allowing a media playback constant from the internal storage or USB key. Supports remote configuration and content management systems, the ViewSonic® CDE7520 is also suitable for a variety of display applications.
* Compatible with Chrome, Android, Windows, Mac OS, and iOS
Now Casting without Dongle gold app Installation
Any computer with a browser
No installation required, just launch the Chrome browser, Chromium or Edge to share your content.
*Application myViewBoard Display built-in for wireless streaming
All the content on a single screen
On all devices with the application
The presentation side-by-side on multiple screens, the display allows all mobile users share their content Full HD.
Gather all remote participants
Web camera 1080p 120 °
The noise reduction, the WDR and the backlight compensation built-in render quality audio-visual of your meeting great in the environments of light and dark.
* VB-CAM-001 (camera) optional
Unique content on all screens
On-site or through the halls with the application
Mirror your content on multiple screens for multi-groups.
Interface OS environment friendly
Built-in player with locations PC OPS and WiFi
* Module optional WiFi & PC OPS VPC12-WPO
Built-in media player
USB plug-and-play photos, music and video
Settings and remote Management of content
myViewBoard manager, SureMDM, Revel Digital and more
Dimensions et ports d’E/S CDE7520W
- AC In
- Power Switch
- Internal Speakers
- OPS Slot
- WiFi Slot
- Menu Controls
- VESA® Wall Mount 400x200mm
- SPDIF
- HDMI In x 2
- DisplayPort
- RS232
- VGA
- Audio In
- USB 3.0 Type A (USB Playback)
- USB 2.0 Type A x 2 (USB Playback)
- Audio Out
- LAN
- ScreenScreen size: 75"+C67:C105C67C67:C128
Type/ Technology: LCD Module TFT. Type-IPS, backlight DLED
Display area (mm): 1649.664(H) × 927.936(V)(75" diagonal)
Native resolution: 3840 x 2160
Height/width ratio: 16:09:00
Color: 1.07 G colors
Brightness: 450 nits (typ.)
Contrast ratio: 1200:1 Typ. 5000:1 Max (DCR enabled)
Response time: 8 ms
Viewing angles: H = 178, V = 178typ.
Backlight life: 30,000 Hours(min)
Surface treatment: Anti-glare, hardness 3H, Haze 25%
Edges: Purpose
Orientation: landscape - INPUTSHDMI: x2
RGB / VGA: x1
DisplayPort: x1
Audio: x1 (3.5 mm)
RS-232: x1
Slot OPS: x1 (Intel OPS VPC12-WPO optional)
Slot WiFi: x1
- OUTPUTSAudio: x1 (3.5 mm)
SPDIF: x1 (Fiber) - LANRJ45: x1
- USBType: 2.0 Type A: x 2 (USB playback), 3.0 Type A: x 1 (USB playback)
- Micro SD card slotMicro SD card slot: No
- SPEAKERSSpeakers: Max. 16Wx2
- COMPATIBILITYRGB PC/HDMI PC: Up to 1920 x 1080 at 60 Hz. Refer to the calendar
HDMI: 480i, 480p,720p,1080i,1080p, 4K2K@60Hz
DisplayPort: 480i, 480p,720p,1080i,1080p, 4K2K@60Hz
Android Version: Android 8.0 - POWERVoltage: 100V-240V,50/60Hz (AC)
Consumption: Normal 107 W - ERGONOMICSWall mount (VESA® ): 400×200 mm
- OPERATING CONDITIONSTemperature (º C): 0 to 40°C
Humidity: 20% ~ 80%, non-condensing - DIMENSIONS (W x H x D)Physical (inch / mm): 65.83 x37.59 x 2.76 in/ 1672.0 x 955.0 x 70.0 mm
Packaging (inch / mm): 71.97 x 43.23 x 8.66 in/1828 x 1098 x 220 mm - WEIGHTNet (lb / kg): 29,30 kg / 64,60 lb (without stand)
Gross (lb / kg): 41.7 kg/91.93 lbs - REGULATIONREGULATION: cULus, FCC, Energy Star, EPEAT,MX-CoC, Mexico Energy, CE, CB, RoHS, ErP, REACH, WEEE, Custom Union, UkrSEPRO, RCM, MEPS
- PACKAGE CONTENTSPACKAGE CONTENTS: 1. Screen CDE7520, 2. Remote control with batteries, 3. Quick start Guide, 4. Power supply Cable (1.5 m), 5. Cable HDMI-IN (3m) 6. Screws for wall mounting, 7. RS232 adapter
