Preview screen commercial 4K CDE5520W
The ViewSonic® CDE5520 is a screen of wireless presentation a 55-inch with a fine and uniform, easy to install for the enterprise environments, point-of-sale, hospitality, hotels..... With a built-in media player, the CDE5520 is able to easily playback high definition content via the port USB. The various connectivity options include 2 HDMI ports-IN, an entry RS232, SPDIF audio output and so on, The CDE5520 the frame end offers sharp, bright images to ensure that images flawless and smooth playback of the content.
Bezel and chassis thin and consistent
With a frame width of only 1.3 cmthis screen commercial/presentation offers stunning visuals in a chassis end.
Bezel 1.3 cm
Play photos, music and videos via USB
A powerful multimedia player multi-core, you can play photos, music and videos in just a few seconds with a simple connection USB.
Built-in media player
Easy Installation on multiple screens
This screen is ideal for configurations multi-screen in the hotels, restaurants, sports bars, or retail outlets that require a dual configuration and presets are customizable.
With a parameter of hospitality programmable USB, each screen has the same settings for the customized channel default, audio level, lock the front panel and automatic start.
Mode hospitality
Settings, Internet / intranet and content management
The software vController offers a simple and intuitive interface for the remote management, the parameters related to the on-screen menu and the programming of content on the monitors deployed through connectivity RS232 or LAN. Compatible software SureMDM and Revel Digital, you can import the media on the screen from any device and anywhere.
vController, SureMDM, Revel Digital
Control multiple HDMI devices
Thanks to the HDMI CEC functionality, the remote control signals can be sent to HDMI devices connected via an HDMI cable. This allows you to directly control DVD drives hidden audio systems and other devices with the remote control screen.
Software sharing content ViewBoard® Cast
ViewBoard® Cast is a content-sharing application for mobile devices *, which allows you to stream content in 1080p from a user's device on ViewBoard® wireless or a wired network. * Compatible with Chrome, Android, Windows, Mac OS, and iOS.
Dimensions and input/output ports CDE5520W
- Internal speakers
- VESA® Compatible wall-mount 400x400mm
- Control panel
- Switch
- AC In
- Input/output infrorouge
- SPDIF
- Audio input/output
- DVI-D In
- HDMI 2.0 In(x2)
- RS232 In
- LAN
- USB 2.0 Type-A(x2)
- ScreenScreen size: 55"
Type/Tech: LCD TFT. Type-IPS, backlight DLED
Display area (mm): 1209.6 (H) x 680.4 (V) (55” diagonal)
Native resolution: 3840 x 2160
Height/width ratio: 16:09
Color: 1.07 Billion colors
Brightness: 400 nits (typ.)
Contrast ratio: 1200:1 Typ.
Response time: 8 ms
Angles of vision: H = 178, V = 178 typ.
Backlight life: 30,000 Hours Min
Surface treatment: Anti-glare, hardness 2H Haze 3%
Edges: Purpose
Orientation: landscape - INPUTHDMI: x2
DVI: x1
Audio: x1 (3.5 mm)
RS-232: x1
IR Pass-Thru: x1 - OUTPUTAudio: x1 (RCA)
SPDIF: x1 (Optical)
IR Pass-Thru: x1
- LANRJ45: x1
- USBType: 2.0 Type A : x2 (USB Drive)
- SPEAKERSSPEAKERS: 10Wx2
- COMPATIBILITYRGB PC/HDMI PC: Up to 1920×1080@60Hz. Refer to the table of frequencies
HDMI: 480i, 480p,720p,1080i,1080p, 4K2K@60Hz
DVI: 480i, 480p,720p,1080i,1080p
Android Version: Android 8.0 - POWER supplyVoltage: 100-240 VAC +/- 10% wide interval
Consumption: Normal 100 W, Max 114.5 W - ERGONOMICSWall mount (VESA® ): 400×400 mm
- OPERATING CONDITIONSTemperature (º C): 0°to 40 ° C
Humidity: 20% ~ 80%, non-condensing - DIMENSIONS (L x H x P)Physical (inch/mm): 48.94 x 28.11 x 2.94 in/1243.2 x 714 x 74.8 mm
Packaging (inch/mm): 55.90 x 35.83 x 9.65 in/1420 x 910 x 245 mm - WEIGHTNet (lb/kg): 16.8 kg / 37.04 lbs
Gross (lb/kg): 23.95 kg / 52.8 lbs - REGULATIONSETTLEMENT: cULus, FCC, Energy Star, TUV Mexico city, Mexico Energy, CE, CB, RoHS, ErP, REACH, EEL, WEEE, RCM
- PACKAGE CONTENTSPACKAGE CONTENTS: 1. Wireless presentation of the CDE5520, 2. Remote control with batteries, 4. Quick start Guide, 5. Power cable (1.8 M), 6. HDMI cable (1.8 M), 7. RS232 cable (1.8 M)
