Description
Carte de réception : Améliorer la qualité de l'image grâce à l'optimisation de chaque pixel
A full calibration of grayscale
Amplifier dynamic
Amplifier image
Calibration complete levels of gray
A full calibration of the gray levels is designed to solve the blocks of colour and the problems of colour-imprecise with the screens, Mini LED and Micro LED. Generating calibration coefficients for each gray level, the consistency of a LED display can be significantly improved.
Amplifier Dynamic
Higher contrast ratio
By improving the light and dark detail of the content at the level of the idea, a source SDR can provide an effect of HDR, ensuring no overexposure in the bright areas and no loss of detail in shadows.
Energy saving with dynamic algorithm
Thanks to the real-time analysis, the brightness is adjusted dynamically frame by frame, which can save 20% to 40% of energy and prolongs the life span of an LED screen.
Amplifier image
The technology, the 22-bit + allows for an improvement in the levels of gray 64 times, with precise control over the brightness of 0.002 nits, offering a picture display fine and vivid even in low-light conditions.
The gray scale accurate to the aid of optical instruments professional allows a more precise control of the brightness of each LED chip, which makes the curve EOTF (such as gamma) much more accurate. The result is a natural image and a better distribution of the colours in low light.
The intelligent management of colours allows a perfect correspondence between the range of colors of the screen and that of the video source. This eliminates the deviation of color, in particular the common problem of skin color reddish brown. This adherence to the original color provided allows the natural beauty of the video source's original shine.
View the world as it should be seen
Auto calibration modules
Double backup of calibration coefficients
After the installation of a new module with flash memory to replace the old one, the calibration coefficients stored in the flash memory can be automatically downloaded to the card face up when it is powered on.
The calibration coefficients are stored simultaneously in the application area and within the area of the factory of the card face. Users typically use the calibration coefficients in the application domain. If necessary, users can restore the calibration coefficients of the area of the plant to the area of application.
The parameters of the configuration file can be restored by pressing a key
Copy of the firmware in one click
The configuration file RCFG can be restored to the factory settings by pressing a single key, restaurant the cabinet to its original configuration. Thanks to this feature, customers no longer need to make a phone call to ask for configuration files.
The cards armoured have the ability to learn automatically the firmware. This allows a card Armor to copy the firmware with any card receiving operational, a feature extremely practical.
Backup card dual
Smart Module
With its small form factor, Armor makes it easy to backup on two cards. The same space that would be occupied by a single card can be used by two cards of receipt Armor to perform a backup to a double card. Even if one of the adapters fails, the display will remain normal.
Monitor the status of the display without monitoring board.A microprocessor (MCU) is added to each module to receive information such as the temperature and voltage of the module, the detection error of a pixel and the calibration coefficients.
A5s More | A7s More | A8s-N | A10s More-N | A10s Pro | |
|---|---|---|---|---|---|
| Loading capacity | 512×384 | 512×512 | 512×384 | 512×512 | 512×512 |
| Groups of RGB data parallel | 32 | 32 | 32 | 32 | 32 |
| Groups of data series | 64 | 64 | 64 | 64 | 64 |
| HDR | × | × | √ | √ | √ |
| Mapping | √ | √ | √ | √ | √ |
| Monitoring of temperature, voltage, and the state of communication | √ | √ | √ | √ | √ |
| Backup card dual | √ | √ | √ | √ | √ |
| Automatic calibration | √ | √ | √ | √ | √ |
| Calibration of the brightness and chroma pixel-level | √ | √ | √ | √ | √ |
| Backup of the calibration factor | × | × | √ | √ | √ |
| Replay of the program of the firmware | √ | √ | √ | √ | √ |
| Gamma individually for RGB | √ | √ | √ | √ | √ |
| 18bit+ | √ | √ | √ | √ | √ |
| 22bit+ | × | × | √ | √ | √ |
| Grayscale accurate | × | × | √ | √ | √ |
| Color management | √ | √ | √ | √ | √ |
| A full calibration of grayscale | × | × | × | × | √ |
| Adjustment of the shutter | × | × | × | × | √ |
| Booster dynamic | × | × | × | × | √ |
