COMING SOON 2023
7KW
32 kWh
Maximum amount of electrical power
Energy storage
Transform sunlight into electricity with photovoltaic system
Can be integrated with heat pump systems heat for heating and cooling
Store the excess energy with the built-in batteries
The unique ability to use different sources of renewable energy to achieve maximum efficiency is its direct analogy with the form platonic of the dodecahedron.
D12 machine is multi-sourced the most powerful, which combines the flow of energy from the Sun, Air, Earth and Water and ensures the production of electricity, heating, cooling and DHW.
The shape of the D12 has a double meaning : it responds perfectly to the needs functional thanks to the balanced relationship between volume and surfaces exposed to and recalls the philosophical sense of the connection between the four elements.
Maximum power
Energy storage batteries storage
D12 is able to heat and cool an area of approximately twelve hundred square feet of a building energy class A, to produce domestic hot water for daily use of up to 30 people and produce electricity for uses related to the system of air conditioning and lighting systems.
This technology helps to reduce the environmental impact by producing and storing of electric and thermal energy exclusively from renewable sources. The use of the dodecahedron, compared to a traditional energy system, allows you to avoid the annual emission of approximately 30 tonnes of CO2.
D12 S
D12 M
D12 L
Maximum amount of electrical power
7kW
7kW
7kW
Electric storage batteries accumulation
16kWh
24kWh
32 kWh
Thermal power for integration heating with heat pump
30kW
50kW
100kW
Thermal power for integrating the cold with heat pump
30kW
50kW
Electrical energy
Heating and cooling
Hot water
The walls of the D12 are carried out with solar panels thin film of last generation and measurement. The absorbing power of the photovoltaic system is strengthened by the presence of a reflective shield at the base of the solid. The light from the sun striking the reflective surface is reflected and diffused in the direction of the faces oriented toward the bottom of the dodecahedron.
The heart and heat of the machine is represented by a geothermal heat pump (or air) and by a system of reservoirs inertial. The electrical energy from photovoltaic panels provides electrical power to the heat pump and its auxiliary devices, while the electric battery is used to store the excess energy accumulated during the daylight hours of greatest production and provides, if necessary, to home users. The inputs and outputs of energy are managed and optimised by a central control system.
100% recyclable
High resistance to weather conditions severe
Warranty 10 years
The walls of the D12 are carried out with solar panels thin film of last generation and measurement. The absorbing power of the photovoltaic system is strengthened by the presence of a reflective shield at the base of the solid. The light from the sun striking the reflective surface is reflected and diffused in the direction of the faces oriented toward the bottom of the dodecahedron.
The heart and heat of the machine is represented by a geothermal heat pump (or air) and by a system of reservoirs inertial. The electrical energy from photovoltaic panels provides electrical power to the heat pump and its auxiliary devices, while the electric battery is used to store the excess energy accumulated during the daylight hours of greatest production and provides, if necessary, to home users. The inputs and outputs of energy are managed and optimised by a central control system.
Electrical power
Electric storage
Energy thermal
Height
Depth’
Length
7kW
16kWh
30kW
4450 mm
5230 mm
5500 mm
7kW
24kWh
50kW
4450 mm
5230 mm
5500 mm
7kW
32 kWh
100kW
4450 mm
5230 mm
5500 mm
-4 ° F to 122 ° F / -20 ° C to 50 ° C
Fixed to the ground
